The Ball Valve (Thread Type) – Inch Version is a powerful Autodesk® Revit® plugin that offers a comprehensive library of leaver-operated ball valve families in inch units. This plugin is designed to enhance the efficiency of piping system modelling for engineers, designers, and BIM professionals. With its accurate geometry, parametric flexibility, and essential configuration options, this family pack is a valuable tool for large-scale BIM projects.
(Image by: JFM)
Key Features
The Ball Valve(TH type) Inch Family Pack provides a range of features that make it a standout plugin for Revit users:
- Supports various valve sizes commonly used in industrial piping systems
- Fully parametric design for flexible modification
- Handle orientation and bolt visibility controlled via parameters
- Optimized geometry for enhanced project performance
- Clean, lightweight families suitable for large BIM environments
- Consistent modelling standards for improved project coordination
- Fully compatible with Revit 2023–2026
(Image by: JFM)
Efficiency and Flexibility
One of the standout features of the Ball Valve(TH type) Inch Family Pack is its fully parametric design, allowing users to easily modify and customize the families to suit their specific project requirements. The ability to control handle orientation and bolt visibility through parameters adds an extra layer of flexibility, making it easier to create accurate and realistic piping system models within Revit.
(Image by: JFM)
Enhanced Project Performance
With optimized geometry and lightweight families, this plugin is designed to improve project performance and efficiency. The clean design of the families ensures that they are suitable for use in large BIM environments without sacrificing accuracy or detail. This optimization makes the Ball Valve(TH type) Inch Family Pack an ideal choice for projects that require smooth coordination and clash detection.
(Image by: JFM)
Conclusion
The Ball Valve(TH type) Inch Family Pack is a valuable addition to any engineer, designer, or BIM professional’s toolkit. With its comprehensive library of leaver-operated ball valve families, parametric flexibility, and optimized geometry, this plugin offers the tools needed to create efficient and accurate piping system models in Revit. Whether working on small-scale projects or large BIM environments, this family pack delivers the performance and reliability needed to streamline the modelling process. Give it a try and experience the benefits for yourself!
